Model TOP

Automatic basket-type centrifugal separator Top-driven model


  • Simple structure of the dischange port reduces adhesive contamination.
  • The model is operable at a number of revolutions as appropriate for the description of the treated substance.
  • All sizes achieve a high centrifugal force (800G).
  • The model with a deep basket has a large filtration area and capacity.
  • The model can be installed in the place subject to explosion-proof requirements.
  • The model reduces maintenance costs.

Exterior dimensions


※Consult with TANABE individually if apparent specific gravity of the wet cake is heavy.
※Detailed data will be supplied at the time of inquiry.

Explanation by an animation

Please feel free to contact us for any inquiry.
