Model CO(CS)

Basket-type centrifugal separator Upper discharge model


  • The basic model with highest applicability is usable for substances in various areas.The model is rated high for performance , operability , safety and durability.
  • Various models , such as those without perforated basket or with skimming device , are available for microparticle treatment.
  • Driving systems include the friction clutch system , inverter system and direct motor connection system.

Drawing of appearance size

Cross section


※Large models such as O-100/110 are also available.
※Slip lined type  can also be supplied.
※Consult with TANABE individually if apparent specific gravity of the wet cake is heavy.
※Detailed data will be supplied at the time of inquiry.
