Model LX

Multi-stage type centrifugal extractor


  • Up to 7 stages installed on a single machine.
  • Compact installation with small footprint. It is possible to set the extractor on the wheeled wagon.
  • Efficient extraction is possible because of the construction of LX type designed by accumulated know-how.
  • Pressurized discharge by impeller. No conveying pump required. ・Remained quantity of liquid in the machine is short in comparison with the capacity. Batch operation is possible.
  • Contacting time of two liquids is short. It is possible to reduce the risk of product degradation.
  • Centrifugation is done after extraction. If the difference in density ratio of two liquids is small, the extraction process is possible.

Cross section
